Copper
Copper Busbars
The Conductor at the Heart of Every Switchboard.
Product sheet
CategoryCopper
Purity99.5% – 99.99%
StandardsIS, ASTM, EN, JIS
OriginMade in India
Product Overview
Keshan copper busbars are manufactured to tight dimensional tolerances for use in switchgear, panel boards, busduct systems, transformers, and high-current distribution equipment — offering high-conductivity performance, precise cross-sections, and a clean surface finish for reliable contact performance in every installation.
Applications
01LV and MV switchgear and control gear
02Busduct and busbar trunking systems
03Power transformers and distribution transformers
04Industrial panel boards and MCC panels
05Battery energy storage systems (BESS)
06EV charging stations and power electronics
Industries Served
Electrical & PowerSwitchgear & PanelsRenewable EnergyRail
Technical Specifications
ProductSpecification — Ranges / Types
Copper Busbars
- Cross section: up to 150 mm
- Width: up to 300 mm
- Thickness: up to 50 mm
- Shape: Rectangular, square, round-edge, and custom corner radius
- Hardness: Soft or Half-hard copper busbars
- Packing: Pancake coils or Straight lengths of custom sizes
- Material: OFC / ETP with minimum 99.90% Cu
- Conductivity: Minimum 100% IACS (soft), minimum 97% (hard)
- Tin coating: minimum 8 microns; silver coating: minimum 0.5 microns
- Standards: IS, BS, DIN, EN, ASTM and customer standards
Why Source From Keshan?
Every batch is traceable, every certificate is verifiable, and every delivery is backed by our technical team. We support custom dimensions, international standards, and complete export documentation.
